Tern GSD S10 400wh

Original price was: $502.00.Current price is: $96.99.

SKU: electric-bikes-cargo-6660931059814 Categories: Brands, Cargo, Electric Bikes, Tern

Reliable Payments for Reliable Shopping
Quality and Affordability Combined
Shop with Confidence, Pay Safely
Quality products, fair prices.

Still Small. Even More Useful.

With a 200 kg (440 lb) Maximum Gross Vehicle Weight, the GSD is ready to replace your car. It’ll let you carry two kids plus groceries, or a whole lot of cargo—but it’s the same length as a regular bike. Built-in dual-battery technology lets you ride all day, while space-saving features like FlatFold and Vertical Parking make the GSD incredibly easy to own and use.

Carries Your Family

The Tern ecosystem of passenger-carrying accessories fits your family—now, and five years from now. Carry two little ones in child seats and watch as they grow into (and out of) the Clubhouse. Give your spouse a lift on date night with the Captain’s Chair. Snap a photo of the day your teen graduates to carrying you.

Features

200 kg Maximum Gross Vehicle Weight
Bosch® Cargo Line Motor provides up to 85 Nm of torque and 400% support
Bosch dual-battery system (400 Wh) for a range of up to 195 km
Shimano® Deore 1 × 10-speed hub for smooth, efficient shifting
Adjustable cockpit comfortably fits riders 150 – 195 cm
Super tough Atlas Lockstand™ auto-locks when engaged—just press a button on the handlebars to unlock
Heavy-duty frame-integrated rear rack and integrated lower decks
Powerful and responsive Magura® MT5 eSTOP 4-piston hydraulic disc brakes
Always-on RearStop™ Brake Light helps you safely signal stops
Integrated Abus® Wheel Lock, keyed-alike with the battery
Upgraded Atlas Wheels™ with custom CNC machined hubs for extra strength and durability
Wide range of cargo- and passenger-carrying accessories
Fits two Thule® Yepp Maxi seats, no adapters needed

Tern GSD S10 400wh -Glow Worm Sales 2022 s10 lr 2

Specifications

General Info

SPEEDS: 1 x 10

WEIGHT: 33.58 kg (74 lb)

GEAR INCHES: 26″ – 99″ (2.08 – 7.91 m)

FOLDING SIZE: 176 × 40.5 × 83 cm (69.3 × 15.9 × 32.7 in)

FOLDING TIME: 5 sec

FRAME SIZES: One size

DISTANCE – SEATPOST TO HANDLEBAR: 49 – 59 cm (19.3 – 23.2 in)

DISTANCE – SADDLE TO PEDAL: 69 – 105 cm (27.2 – 41.3 in)

SUGGESTED RIDER HEIGHT: 150 – 195 cm (59.1 – 76.8 in)

MAX GROSS VEHICLE WEIGHT: 200 kg (440.9 lb)

MAX RIDER WEIGHT: 120 kg (264.6 lb)

FRAME

FRAME: Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg

FORK: Suntour custom for Tern, 1.5″ tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg

COCKPIT

HANDLEPOST: Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm

STEM: Tern Andros, adjustable, forged construction, patented technology

HEADSET: Tern Flux Pro Taper, 1.5″, angular contact bearings, Physis integrated

HANDLEBAR: Tern Sweep, 6061-AL, Tern Andros adapted

GRIPS/BAR TAPE: Ergon

SADDLE: Tern GSD by Velo, with rear handle

SEATPOST: Tern Telescope, 34.9/30.9 mm, 2014-AL

SEATPOST CLAMP: Tern Collar, 6061-AL, 2pc

BRAKES

FRONT BRAKE: Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads

REAR BRAKE: Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads

BRAKE LEVERS: Magura MT5 e-stop, hydraulic, with brake sensor

WHEELS

FRONT HUB: Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing

REAR HUB: Tern Atlas, Boost Thru-Axle, Syntace X-12 standard, Cargo-optimized design

SPOKES AND NIPPLES: Stainless steel, 13G

RIMS: Tern Atlas, ultra wide 36 mm, dual reinforced joint

TIRES: F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex

TRANSMISSION

SHIFTER(S): Shimano Deore, 1 x 10 spd

REAR DERAILLEUR: Shimano Deore Shadow+

CRANKSET: Tern GSD custom, forged 6061-AL DH crankarm

CASSETTE/FREEWHEEL: Shimano 11-36T, 10 spd

BOTTOM BRACKET: Motor integrated

CHAIN: 10 spd, DHT for eBike, GST corrosion resistant coating

PEDALS: Urban with non-slip surface, sealed bearings

SHIFTER CABLE & HOUSING: Jagwire LEX-SL, slick treatment, alloy ferrules

E-SYSTEM

MOTOR: Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)

BATTERY: Bosch Dual Battery system, 400 Wh/500 Wh

DISPLAY: Bosch Purion, 4 mode selectable, walk assist

RANGE: 400 Wh: 42-85 km / 500Wh: 60-140 km

CHARGER: 220V, 4A (EU); 100-240V, 4A (US)

BELLS & WHISTLES

BELL: Pitch Plus, brass

CHAINGUARD: Tern Custom, full chain cover

KICKSTAND: Atlas Lockstand, w/ remote unlock, patented technology

LUGGAGE SOCKET: Combo Mount

FRONT LIGHT: Tern Valo Direct, 190 lumens

REAR LIGHT: RearStop Brake Light, Always on brake light

FENDERS: Integrated Wheel Guard, AL6061, w/ Side Skirt

RACK(S): Frame integrated, heavy duty design; Max load weight: 100 kg (220 lb)

ACCESSORY: ABUS, keyed-alike with Bosch battery

Sizing

One Size Fits Most

The GSD has an adjustable cockpit that resizes in seconds and without tools to fit riders 150 – 195 cm tall (4’11” – 6’5”), so you can easily share it with your family. The updated frame geometry with a slacker seat tube angle and higher handlebars also means the GSD doesn’t just fit—it’s more comfortable too.

Tern GSD S10 400wh -Glow Worm Sales 2022 GSD G2 fitsthefamily

Warranty

Intended Use

Tern provides two different warranties based on the type of road the bicycle model was designed to be ridden on:

1. Graded and Maintained Gravel Roads (HSD, GSD)

This Tern bike is designed for individual personal use: riding with both wheels in contact with paved roads or graded and maintained gravel roads.

2. Paved Roads Only (All other Tern bicycles)

This Tern bike is designed for individual personal use: riding with both wheels in contact with paved roads only.

In addition, all Tern bikes are not intended for racing, jumps, hops, wheelies, or similar activities which may cause damage to the bicycle and risk injury or death to the rider.

The warranty information below refers to all Tern bicycles.

Limited Warranty

Tern bicycles are sold on behalf of our company (“Tern”) by selected Authorized Tern Dealers who understand the assembly and service needs of our products. Tern provides a warranty against defects in materials and workmanship to the original retail purchaser (“Owner”) of a Tern bicycle from the date of purchase according to the following terms:

Five Years: Frame, Handlepost, and Fork
One Year: All Tern or BioLogic branded parts and components, except as noted below.
Other: Any other parts or components are covered by the stated warranty of the original manufacturer of that part or component.

This warranty supersedes any other warranty supplied by Tern.

Extended 10-Year Warranty

Owners who sign up for Tern Care will be covered by an extended 10-year warranty for the Frame, Handlepost, and Fork, as long as they sign up within 30 days of purchase and are the original purchasers. In addition, the bike must have been assembled by an Authorized Tern Dealer at the time of purchase—regardless of whether the bike was purchased from a physical or online store.

The following items are excluded from the extended 10-year warranty:

Paint finish
Bikes for commercial use
All other parts not specifically listed (for example, but not limited to: Motorized Drive System)

The warranty does not mean that the Frame, Handlepost, and Fork are indestructible. All materials can fail if pushed beyond design and manufacturing limits. It simply means that these items are covered under the specific terms of this limited warranty.
